VisualARQ

VisualARQ by F.Salla adds flexible BIM features to Rhino, and speeds up the process of modeling an architectural project in 2D and 3D. VisualARQ provides tools to generate all project document information (plans, sections, elevations) and quantification (surfaces, dimensions, components, quantities) from the 3D model automatically.

VisualARQ imports & exports IFC files to exchange architectural BIM models between Rhino and other AEC software. You can also tag any object with an ifc category and add custom information to geometry, which will be exported as ifc properties.

VisualARQ has a library set of parametric architectural objects (walls, windows, doors, beams, stairs…) that can be also created from Grasshopper definitions, providing unlimited options for parametric BIM object designs. All VisualARQ objects and information assignment can be created from Grasshopper with the VisualARQ Grasshopper Components.
