OpenNest Grasshopper3d Plugin

OpenNest

OpenNest by petras_vestartas is a Grasshopper plugin with tools for unrolling, packing and of course nesting curves directly inside the definitions. The library is based on Boost 1.62 that is used to compute NFP – No Fit Polygon.

Continue reading

FlowL Grasshopper3d Plugin

FlowL

flowL by uto is a plug-in to visualize a vector field, generated through positive and negative point charges. The path lines are calculated with the “Runge-Kutta 4th Order Method” short “RK4”.

Continue reading

Wasp Grasshopper3d Plugin

Wasp

Wasp by Andrea Rossi is a set of Grasshopper components, developed in Python, directed at representing and designing with discrete elements. The description of each individual part includes basic information necessary for the aggregation process.

Continue reading

SuperMesh Toolkit Grasshopper3d Plugin

SuperMesh Toolkit

SuperMesh Toolkit by George Adamopoulos allows you to easily design a large variety of regular or irregular patterns on NURBS Surfaces of any curvature, by tessellating them to special quad-like Meshes, topologically structured in rows and columns.

Continue reading

Discrete Vectors Pufferfish Plugin Grasshopper3d

Discrete Vectors

Discrete Vectors by ekimroyrp is a set of components for making discrete vectors out of continuous or random vector sets. Good for matching vectors to other closest predefined vectors to give curves, swarms, and flowlines that straight line aesthetic.

Continue reading

BrickDesign Grasshopper3d Plugin

BrickDesign

BrickDesign by ROB Technologies enables the controlled design and manipulation of a large amount of discrete elements. The plug-in provides a parametric design environment, which allows for a fast build-up of brick façade geometries.

Continue reading

Paneling Tools Rhino3d Grasshopper3d Plugin

Paneling Tools

PanelingTools plugin by Robert McNeel & Associates is integrated with Rhino and Grasshopper and is widely used by designers, architects, and building prefessionals. It supports intuitive design of paneling concepts as well as help rationalize complex geometry.

Continue reading

Flatworm Grasshopper3d Plugin for generating rigidly foldable quadrilateral meshes RFQM and Miura Ori fold

Flatworm

Flatworm by jakobl is a GHPython implementation of the pure-python module RFQM.py for generating ‘rigidly foldable quadrilateral meshes’ (RFQM) in Grasshopper. Flatworm provides basic means of generating Miura Ori fold pattern as well.

Continue reading

Intralattice Grasshopper3d Plugin

Intralattice

Intralattice by dnkrtz, is a plug-in for Grasshopper used to generate solid lattice structures within a design space. It was developed as an extensible, open-source alternative to current commercial solutions, such as Within.

Continue reading

Cocoon Grasshopper3d Plugin

Cocoon

Cocoon by David Stasiuk is an add-on to McNeel’s Grasshopper visual scripting interface for Rhinoceros. Cocoon is a fairly straightforward implementation of the Marching Cubes algorithm for turning iso-surfaces into polygonal meshes.

Continue reading
